300W Pulse Fiber Handheld Laser Cleaning Machine Raycus Max IPG JPT Optional

Place of Origin China
Brand Name DP LASER
Certification CE SGS FDA TUV ROHS
Model Number Laser Cleaning Machine
Minimum Order Quantity 1 Set
Price Please contact us
Packaging Details Wooden boxes that meet international export standards
Delivery Time 7-15 Work Days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 300 set/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Laser Source Raycus Max IPG JPT Optional Laser Type Pulse Fiber Laser
Laser Source Type Pulse Fiber Laser Application Metal Stainless Steel Cleaning
Clean Way NON-TOUCH CLEANING Laser Power 300W Optional
Dimension(L*W*H) 642*1056*1089mm Weight (KG) 200 KG
Power Supply 110V/220V 50HZ After-sales Service Provided Overseas Engineers Provide Door-to-door Service
High Light

300W Handheld Laser Cleaning Machine

,

JPT Handheld Laser Cleaning Machine

,

Raycus IPG hand held laser rust remover

Leave a Message
Product Description

Handheld 300W Pulse Fiber Laser Cleaning Machine Metal Products Cleaner


Features
1. Non-contact processing, no consumables, no damage, no chemical pollution
2. Handheld laser cleaning head, light, convenient and easy to use
3. Right angles, corners and grooves can be cleaned
4. Derusting, decontamination, degreasing, deoxidation



Application industry

It is mainly used for laser cleaning and surface laser pretreatment of metal surfaces such as precision molds, metal products, ships, automobiles, medical equipment, sheet metal/spraying, etc.
300W Pulse Fiber Handheld Laser Cleaning Machine Raycus Max IPG JPT Optional 0300W Pulse Fiber Handheld Laser Cleaning Machine Raycus Max IPG JPT Optional 1300W Pulse Fiber Handheld Laser Cleaning Machine Raycus Max IPG JPT Optional 2300W Pulse Fiber Handheld Laser Cleaning Machine Raycus Max IPG JPT Optional 3

Laser Power 200W 300W
Laser Source Raycus/IPG Raycus/IPG
Central Wavelength 1064±5 1064±5
Power Regulation Range 10-100 10-100
Outpit Power Instability ≤5 ≤5
Output Power Instability 10-50 20-50
Pulse Length 90-130 130-140
Maximum Monopulse Energy 10 12.5
Fiber Length 5/10m 5/10m
Laser Protection Class 4 4
Cooling Type Water Cooling Water Cooling
Dimensions 642*1056*1089mm 642*1056*1089mm

300W Pulse Fiber Handheld Laser Cleaning Machine Raycus Max IPG JPT Optional 4300W Pulse Fiber Handheld Laser Cleaning Machine Raycus Max IPG JPT Optional 5300W Pulse Fiber Handheld Laser Cleaning Machine Raycus Max IPG JPT Optional 6


Cleaning Performance Parameters
Based material Surface Effective focal length Standard cleaning efficiency High cleaning efficiency Result
Cast iron Heavy rust 0.08mm >35mm 2000mm/m 3000mm/m Clean, no harm for base material
Mild steel Middle rust 0.5mm >45mm 1800mm/m 2400mm/m Clean, no harm for base material
Stainless steel Oil, light rust >50mm 2000mm/m 3000mm/m Clean, no harm for base material
Mould gear Middle oil with scrap iron >45mm 2000mm/m 2300mm/m Clean, no harm for base material
Aluminum oxide >35mm 2000mm/m 2300mm/m Clean, no harm for base material



DP Laser cleaning machine has advanced technology, with humanized design, small size, flexible operation, low energy consumption, environmental protection and other characteristics, with certain practicability and operability. Customers can preset the cleaning mode through the software, and can directly switch the mode to operate without adjusting the parameters, and start cleaning without chemical reagents, media, dust and water. Through automatic focusing, cleaning the surface of the object, and removing resin, stains, corrosion, coatings, paints, etc. on the surface of the object, the cleanliness is high.
