High Speed Automatic Feeding Fiber Laser Cutting Machine Round Pipe

  • High Speed Automatic Feeding Fiber Laser Cutting Machine Round Pipe
  • High Speed Automatic Feeding Fiber Laser Cutting Machine Round Pipe
Place of Origin China
Brand Name DP LASER
Certification CE SGS FDA TUV ROHS
Model Number Laser Cutting Machine
Minimum Order Quantity 1 Set
Price Please contact us
Packaging Details Wooden boxes that meet international export standards
Delivery Time 10-30 Work Days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 300 set/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Laser Source Raycus MAX IPG NLIGHT Laser Source Laser Power 1000W-3000W
Power Supply 380V/50HZ Maximum Acceleration 1.5G
Feature SERVO-MOTOR Cutting Speed 150m/min
Cutting Thickness 0-80mm Weight (KG) 2000 KG
Cutting Materials Stainless Steel Carbon Steel Etc Name Fiber Cutting Machine
Laser Mode Single Mode
High Light

Automatic Feeding Fiber Laser Cutting Machine

,

High Speed Fiber Laser Cutting Machine

,

380V 50HZ Automatic Cutting Machine
Leave a Message
Product Description

High Speed Automatic Feeding Fiber Laser Cutting Machine Round Pipe



High Speed Automatic Feeding Metal Round Pipe Fiber Laser Cutting Machine



The laser cutting process involves using the optical path system to focus the laser beam emitted from the laser into a high power density laser beam. This beam is then directed onto the surface of the workpiece, causing it to reach its melting or boiling point. At the same time, the high-pressure gas that is coaxial with the beam blows the molten or vaporized metal away. By moving the beam and the workpiece relative to each other, a slit is formed in the material, allowing for the desired cut to be made.



Apply to Auto feeding round pipeφ≤89mm,Square pipe≤63*63mm
Cutting accuracy ±0.3mm,Tube bend≤2mm/m
Feeding length 4000mm-6200mm

Primary filler weight



 According to the size of the pipe, the storage space of the trough is limited, and the maximum load1.5t
Laser power 1000W/1500W/2000W/3000W
Laser wavelength 1070nm±5nm
laser mode single mode
Photoelectric conversion efficiency 30%
Working way continuous
Power adjustment range 5-95%
Power instability ≤2%
Transmission fiber core diameter 25um-50um
Fiber length 10m
Cooling method Water cooling
Chiller model C1000/C1500/C2000/C3000 Double temperature double circulation chiller
Cooling water temperature 20-25℃
Power supply AC380±10%,50/60Hz
Working temperature 10~35℃
Working environment humidity ≤95%
Total weight 2T



Features

Laser cutting is characterized by its fast speed and ability to create smooth and flat incisions that often require no additional processing.

Another advantage of laser cutting is that it produces a small heat-affected zone, which minimizes plate deformation and results in a narrow cutting seam.

Additionally, laser cutting produces incisions without any mechanical stress and eliminates the need for shearing burrs.

With high machining accuracy and good repeatability, laser cutting does not damage the surface of the material being worked on.

Finally, laser cutting offers the benefits of numerical control programming, which enables the processing of any plan and the cutting of large-format boards without the need for mold opening, making it an economical and time-saving option.



Applicable Industries

Mainly used in sheet metal processing, advertising sign production, high and low voltage electrical cabinet production, mechanical parts, kitchen utensils, automobiles, machinery, metal handicrafts, saw blades, electrical parts, glasses industry, spring sheets, circuit boards, electric kettles, medical micro Electronics, hardware, knives and measuring tools and other industries.

High Speed Automatic Feeding Fiber Laser Cutting Machine Round Pipe 0High Speed Automatic Feeding Fiber Laser Cutting Machine Round Pipe 1




High Speed Automatic Feeding Fiber Laser Cutting Machine Round Pipe 2



High Speed Automatic Feeding Fiber Laser Cutting Machine Round Pipe 3
