100W 200W Portable Fiber Laser Cleaner Machine Raycus Laser Source Trolley Case

Place of Origin China
Brand Name DP LASER
Certification CE SGS FDA TUV ROHS
Model Number Laser Cleaning Machine
Minimum Order Quantity 1 Set
Price Please contact us
Packaging Details Wooden boxes that meet international export standards
Delivery Time 7-15 Work Days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 300 set/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Laser Source Raycus Laser Power 100W 200W Optional
Power Supply 110V/220V Laser Type Pulse Fiber Laser
Application Metal Stainless Steel Cleaning Condition New
Feature NON-TOUCH CLEANING Scan Width 1-150mm
Weight (KG) 30 KG After-sales Service Provided Overseas Engineers Provide Door-to-door Service
High Light

100W portable fiber laser cleaner

,

200W portable fiber laser cleaner

,

Raycus portable fiber laser cleaning machine

Leave a Message
Product Description

100W 200W Raycus Laser Source Trolley Case Portable Fiber Laser Cleaning Machine



Basic introduction

Laser cleaning has the characteristics of no grinding, non-contact, no thermal effect and suitable for objects of various materials, and is considered to be the most reliable and effective solution. At the same time, laser cleaning can solve problems that cannot be solved by traditional cleaning methods.


Features

1. No consumables, no chemical pollution, no noise, energy saving and electricity saving.



2. No contact, no grinding, no stress, little damage to the substrate.



3. It can eliminate the pollution particles below the nanometer level, and the cleanliness is high.



4. Optical fiber transmission, movable operation, can clean up dead spots.



5. Simultaneous cleaning and synchronous processing to achieve zero discharge during the cleaning process.



6. It can realize fast cleaning of heavy pollutants and high-speed cleaning of light pollutants.



Application industry

Laser cleaning can be used not only to clean organic pollutants, but also to clean inorganic substances, including metal rust, metal particles, dust, etc. It is mainly used in the cleaning of molds, weapons and equipment, old aircraft paint, exterior walls of buildings, electronics industry, precision de-esterification in precision machinery industry, and pipelines in nuclear power plant reactors.
100W 200W Portable Fiber Laser Cleaner Machine Raycus Laser Source Trolley Case 0

Cleaning Performance Parameters
Based material Surface Effective focal length Standard cleaning efficiency High cleaning efficiency Result
Cast iron Heavy rust 0.08mm >35mm 2000mm/m 3000mm/m Clean, no harm for base material
Mild steel Middle rust 0.5mm >45mm 1800mm/m 2400mm/m Clean, no harm for base material
Stainless steel Oil, light rust >50mm 2000mm/m 3000mm/m Clean, no harm for base material
Mould gear Middle oil with scrap iron >45mm 2000mm/m 2300mm/m Clean, no harm for base material
Aluminum oxide >35mm 2000mm/m 2300mm/m Clean, no harm for base material

100W 200W Portable Fiber Laser Cleaner Machine Raycus Laser Source Trolley Case 1

Laser Power 100W 200W
Laser Source Raycus Raycus
Fiber Length 3m 3/5m
Cooling Type Air Cooling Air Cooling
Input Power 220V 220V
Power <500W <1300W
Dimensions 575*408*270mm 685*538*411mm
Total Weight 30KG 65KG
Scan Head Weight 2KG 2KG

100W 200W Portable Fiber Laser Cleaner Machine Raycus Laser Source Trolley Case 2100W 200W Portable Fiber Laser Cleaner Machine Raycus Laser Source Trolley Case 3

DP Laser cleaning machine has advanced technology, with humanized design, small size, flexible operation, low energy consumption, environmental protection and other characteristics, with certain practicability and operability. Customers can preset the cleaning mode through the software, and can directly switch the mode to operate without adjusting the parameters, and start cleaning without chemical reagents, media, dust and water. Through automatic focusing, cleaning the surface of the object, and removing resin, stains, corrosion, coatings, paints, etc. on the surface of the object, the cleanliness is high.

100W 200W Portable Fiber Laser Cleaner Machine Raycus Laser Source Trolley Case 4

100W 200W Portable Fiber Laser Cleaner Machine Raycus Laser Source Trolley Case 5

100W 200W Portable Fiber Laser Cleaner Machine Raycus Laser Source Trolley Case 6

100W 200W Portable Fiber Laser Cleaner Machine Raycus Laser Source Trolley Case 7
